AVer MD120UI

R57 790,00 incl. VAT

MONITORING WITHOUT DISTANCE

The AVer MD120UI is the groundbreaking PTZ camera specifically designed for patient monitoring. Powered by advanced AI technologies, monitoring patients has become a breeze, allowing healthcare providers to stay vigilant and attentive to their patients’ needs. 20X optical zoom & 4K imaging capabilities along with IR night view f unc ti on provi d e c rys ta l – c l ear vi s ual monitoring of patients, enabling 24-hour patient monitoring with no blind spots.

Share:

Superb Camera Quality

Thanks to MD120U’s superior autofocus, zoom speed, and rapid camera movements, the 4K resolution at 20X optical zoom lens is able to capture even the smallest of details. This allows doctors and healthcare providers to make precise assessments efficiently with the help of up to 256 preset points provided by the camera.

Innovative AI Technologies

The MD120U is equipped with state-of-the-art AI algorithms that facilitate the automatic detection of patient’s body contour and capture specific areas of interest on patients, such as face and eyes (AI Facial/Eyes Tracking). By utilizing the AI modes, medical professionals can monitor patients and take necessary precautions with increased efficiency. Furthermore, AVer is creating more AI modes to further assist medical professionals and patients.

Your Privacy Matters

In any healthcare setting, it is crucial to respect patients’ trust and privacy. By activating MD120U’s Privacy Mode, the transmission of video and audio data can be stopped, ensuring that no information leaves the ward. Rest assured that your privacy is protected.

Built-in Microphone for Better Real-time Monitoring

Embedded microphone can transmit all sounds in the patient room to the nursing station, alerting medical staff of real-time, crucial information for proper intervention and offering more possibilities for enhancing virtual care settings.

24/7 Monitoring with Night Vision

The MD120U has moved patient monitoring a step forward with its Infrared Night Vision function. This makes 24/7 patient monitoring possible. Healthcare providers can monitor patients around the clock without disturbing patient’s sleep or compromising their own safety, providing secure and efficient patient care.

Additional information

Weight 1,7 kg
Dimensions 145 × 180 × 183,5 mm
Camera Audio
Image Sensor: 1/2.8" CMOS
Effective Picture Elements: 8 Megapixels

Output Resolutions:
Resolutions: 4K / 1080p / 720p
Frame Rates: 60 / 59.94 / 50 / 30 / 29.97 / 25

Minimum Illumination: 0.5 Lux (50 IRE, F1.6, Max. AGC, 1/30)
S/N Ratio: ≥ 50 dB
Gain: Auto, Manual
TV Lines: 1000 (Center / Wide)
Shutter Speed: 1/1 to 1/10,000s
Exposure Control: Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance: Auto / Manual

Optical Zoom: 20X
Digital Zoom: 12X
Total Zoom: 20X

Viewing Angles:
DFOV: 69.2° (Wide) to 4.1° (Tele)
HFOV: 62.3° (Wide) to 3.6° (Tele)
VFOV: 37.7° (Wide) to 2.1° (Tele)

Focal Length: f = 4.5 mm (Wide) to 90 mm (Tele)
Aperture (Iris): F = 1.8 (Wide) to 4.7 (Tele)

Minimum Working Distance:
0.1 m (Wide), 1.2 m (Tele)

Pan / Tilt Angles:
Pan: ±170°; Tilt: +90° / -30°
Pan / Tilt Speed (Manual):
Pan: 0.1° to 100° / sec; Tilt: 0.1° to 100° / sec

Preset Speed:
Pan: 200° / sec; Tilt: 200° / sec
Preset Positions: 10 (IR), 256 (RS-232, RS-422, IP)

Camera Control - Interfaces:
RS-232 / RS-422 / Ethernet

Camera Control - Protocols:
VISCA (RS-232 / RS-422 / IP), CGI (IP)

Image Processing:
Mirror / Flip / Freeze / WDR / BLC

Power Frequencies: 50 Hz, 60 Hz
Channels: 2ch Stereo
Codec: AAC-LC (48k)
Built-in Microphone: 1 (Omni-Directional)

Interface:
Video Outputs: HDMI, IP, USB
Audio Outputs: HDMI, IP, USB
Audio Inputs: N/A
AI Function IP Streaming
Mode: Eye Tracking
Resolution: 4K@60fps
Network Video Compress Formats: H.264, H.265, MJPEG
Maximum Frame Rate: 4K 60fps
Bit-Rate Control Modes: VBR, CBR
Range of Bit-Rate: 512Kbps to 64Mbps
Network Interface: 10 / 100 / 1000 Base-T
Multi-Stream Capability: 2 (RTSP / Web page), 4K/60fps Max.
Network Protocols:
IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP,
RTP/RTCP, RTSP, RTMP, VISCA over IP
Privacy USB
Protection Mode:
Privacy Mode, Privacy Indicator
Connector: USB 3.0 (Type-B)
Video Formats: MJPEG
Maximum Video: 2160p
USB Video Class (UVC): UVC 1.1
USB Audio Class (UAC): UAC 1.0
General Web UI
Power Requirement: 12V
Power Consumption: 24W
PoE: (IEEE802.3at)
Dimensions (W × H × D): 180 × 145 × 183.5 mm
Net Weight: 1.7 (±0.1) kg
Housing Material: Anti-UV
Application: Indoor
IR Night Vision: Yes
Security: Kensington Slot
IR Remote Control: Yes
Operating Conditions:
Temperature: 0°C to +40°C; Humidity: 20% to 80%
Storage Conditions:
Temperature: -20°C to +60°C; Humidity: 20% to 95%
Live Video Preview: Yes

Camera PTZ Control: Pan, Tilt, Zoom, Focus, Preset Control

Camera / Image: Exposure, White Balance, Picture

Network Configuration:
DHCP, IP Address, Gateway, Subnet Mask, DNS
Software Tools Warranty
IP Search and ConfigurationTool:
Support Windows® 7 or later

PTZ Management: AVer ViewCare

PTZ Control Panel:
Supports iOS® & iPadOS® 11 or later

OBS Plugin:
Supports Windows® 7 or later, macOS® 10.14 or later
Camera: 3 Years
Accessories: 1 Year
Package Contents
Camera, Drilling Paper, Ceiling Mount Bracket, Quick Start Guide, Cable Fixing Plate,
M2.7 × 4 mm Screw (×3), Power Adapter & Power Cord, 1/4”-20 L × 6.5 mm Screw (×2),
Remote Control, M3 × 6 mm Screw (×3), USB Cable (Type-B)
Optional Accessories
AVer CC01 PTZ Camera Controller, L-Type Wall Mount
