CAM520 Pro 3

R27 830,00 incl. VAT

Lens and Boost Your Business Masterful Navigating and Presenting

The AVer CAM520 Pro3 is extremely versatile, offering users a 36X total zoom PTZ camera, upgraded AVer SmartFrame, Preset Framing, and a Sony WDR Sensor. In addition, 3-way outputs — including an HDMI connection — deliver more streaming options. But what makes the CAM520 Pro3 truly special is Smart Composition, an embedded AI function that quickly captures meeting participants’ images to facilitate productive video conferences in mid-to-large meeting rooms.

Share:

Master the Details with a 36X* Total Zoom Lens and Boost Your Business

Create error-free meetings with the CAM520 Pro3 PTZ lens. Capture wide shots with an 80° diagonal field of view, and focus on presenters, attendees, content on whiteboards or digital objects with flexible pan and tilt controls. Powerfully render every detail with a 12X optical lens and a 3X* total zoom. Additionally, the CAM520 Pro3 uses 24X lossless zoom to deliver outstanding clarity to remote participants, making it the ideal conferencing camera for mid-to-large rooms!
*Use PTZApp 2 to enjoy 3X* zoom functionality.

Accurately Capture Attendees with AVer Smart Composition to Access Layout Flexibility

The CAM520 Pro3 is one of the first PTZ cameras in the video conferencing industry to include a Smart Composition function — a feature typically reserved for higher-end devices. Smart Composition uses an AI algorithm to automatically crop each participant’s face or body in a perfect frame. This is a click-to-play feature that doesn’t require any software to set up! Smart tracking is designed to shoot fluid body views, and smoothly convert from an individual view to a group image. The CAM520 Pro3 delivers high-definition views of participants for stress-free meeting setups and ultimate productivity.
*Works for up to 6 people.

More Efficiency and Security with Upgraded AVer SmartFrame

With enhanced SmartFrame, AVer’s CAM520 Pro3 elevates your meeting efficiency and safety. This AI technology automatically focuses on participants, working effortlessly from an impressive distance of up to 7 meters away — even when people are wearing masks!

The CAM520 Pro3 also provides a Preset Framing mode that efficiently follows presenters through preset areas. By setting multiple preset areas, the framing mode within the camera will automatically shift as the presenter moves without any manual control!

HDMI Enables Dual Display and 3-Way Output, Creating Diverse Display Options

Simultaneously presenting in 1080p/60fps via HDMI and USB 3.1 streaming or RTSP/RTMP H.264 broadcasting, the CAM520 Pro3 lets you use 2nd display for virtual meetings. These connection options allow you to create seamless hybrid meeting experiences for your business.

Enjoy Enterprise-Grade Imaging with No limits

The CAM520 Pro3 provides lifelike meetings even in high-contrast backlighting environments — such as meeting rooms with multi-lighting, projectors, or bright screens. With the advanced light sensor powered by AI, the CAM520 Pro3 automatically reviews lighting shadows, allowing the white balance to overcome various environmental impacts. With features like Camera Control, AVer Virtual Streaming, and AI Smartframe, you can use the CAM520 Pro3 as a video source for virtual meetings. It streamlines the setup process and reduces installation expenses. You deserve to experience enterprise-grade imaging in every meeting.

Additional information

Weight 1,47 kg
Dimensions 182 × 142,7 × 153 mm
Product Specifications
Camera • Sony super-low-light 8M pixel sensor
• Resolution: (16:9) 1920×1080, 1280×720… etc.
• Frame rates: 60/30/15fps
• SmartFrame auto FOV adjustment
• Smart Composition framing
• WDR up to 120dB
• Zoom: 36X total zoom (12X optical)
• Field of view: DFOV=80.5° / HFOV=72.9° / VFOV=44.1°
• Lens focal length: 3.9mm (wide) → 46.8mm (tele)
• Lens F#: 1.6 (wide), 2.8 (tele)
• Mirror, Flip, AE, AWB control via PTZApp 2
• Min focus distance: 1m
• Kensington slot
• People-counting API
*Use PTZApp 2 to set up 36X zoom.
Motorized Pan & Tilt Movement • Pan: ±170°
• Tilt: +90° (up), −30° (down)
• 10 camera presets
• Fast & quiet movement
Video Format • YUV, YUY2, MJPEG
• Network video compression: H.264
• Protocol: RTSP, RTMP
Control • IR remote
• VISCA / Pelco P / Pelco D via RS232
• UVC plug and play
• WebUI browser IP access
• PTZApp 2
Connectivity • 12V/2A power adapter
• Mini DIN9 for RS232 in/out
• USB 3.1 type-B
• RJ-45
• HDMI 1.4
USB • USB 3.1 Gen 1 Type-B
• UVC1.1, UVC1.5*
Mount • Camera wall mount bracket included
• Optional foldable TV mount
• Optional ceiling mount
System Requirements • Windows® 7/10/11
• macOS X 10.7 or later
• ChromeOS version 94+
PC Hardware Requirements • Intel® Core™ i5–4460 or later
• 8 GB RAM or more
• USB 3.1 port recommended
Environmental Data • Operating temp: −20°C ~ 40°C
• Operating humidity: 20% ~ 80%
• Storage temp: −20°C ~ 60°C
• Storage humidity: 20% ~ 80%
Dimensions • Package dimensions: 265 × 265 × 274 mm
• Package weight: 3.385 kg / 7.35 lbs
• Camera: 182 × 142 × 153 mm / 1.47 kg
• Remote control: 200 × 50 × 21 mm / 0.09 kg
Optional Accessories • Mini DIN 8 to SUB9 RS232 adapter
• USB3.1 3m Type-B to Type-A cable
• HDMI cable
• Ceiling mount
• 1-port PoE+ Injector
• Foldable TV mount
Web Browser Requirement • Chrome v76+
• Firefox v69+
• IE: Not supported
Power Supply • AC 100 ~ 240V, 50/60 Hz
• Consumption: 12V, 2A
• PoE+: 802.3at
Package Contents • CAM520 Pro3 unit
• Remote control
• 5m USB2.0 Type-B to Type-A cable
• Power adapter (10 ft / 3m)
• QR code card
• Wall mount bracket
• 1× tripod screw
• Mini DIN 9 to DIN 8 RS232 adapter
Warranty • Camera: 3 years*
• Accessories: 1 year
*Extended warranty in some regions.
Compatible Applications Zoom, Microsoft Teams, Skype, Webex, Google Meet, RingCentral, BlueJeans, V-Cube, GoToMeeting, OBS, Wirecast, vMix, XSplit and more.
