CAM570

R49 815,00 incl. VAT

AVer CAM570 is a 4K dual lens camera with a 36X Total zoom PTZ camera and a second AI lens with 95˚FOV. Equipped with built-in audio sensor, CAM570 detects human voices up to 10M and offers audio tracking function. AI technology such as Smart Gallery and gesture control can capture every attendees up-close with premium video quality.

Share:

Built-in Audio Sensor Enables Audio Tracking

Easily focus on active speaker with audio tracking mode and presentation mode. The camera will follow the speaker automatically or you can set up a preset point to focus on a specific area. The built in sensor picks up human voices up to 10M without being disturbed by a local speakerphone.

Dynamic Detection Optimizes Meeting Experience

The dual lens design detects real time motion precisely while offering a complete view of the room simultaneously. When the second AI lens detects a newcomer walking in it triggers the first PTZ camera to re frame the participants, ensuring all meeting attendees are instantly captured again for a seamless collaboration in real time.

Smart Gallery Delivers a Clearer View of Faces

Perfectly see everyone in the room. Thanks to AI technology, Smart Gallery crops meeting attendees and display them in equal individual feeds. Highlight participants’ facial and body expressions, leading to effective hybrid meetings.

Interact with CAM570 Using Touchless Gesture Control

With the application of AI to recognize gestures and interpret commands, you can turn on/off the tracking function and zoom in/out without any direct physical touch. Minimize the touch points and improve workplace hygiene.

Picture-in-Picture Displays Preferred Conference View

CAM570 includes a PTZ camera with 36X Total zoom and a second AI lens to provide a panoramic view. The dual lens design offers a speaker view and wide angle view simultaneously with various PIP layout options. Ideal for larger and more complex meeting spaces.

Additional information

Weight 2,1 kg
Dimensions 170,8 × 173 × 190,5 mm
Product Specifications
Dual Camera • PTZ optical zoom lens
• Image sensor: Sony 4K EXMOR, crystal clear in any lighting
• Frame rates: (16:9) 4K 30fps; 1920 × 1080, 1600 × 900, 1280 × 720, 960 × 540, 848 × 480, 800 × 448, 640 × 360 at 60, 30, 15fps; (4:3) 1280 × 960, 800 × 600, 640 × 480 at 60, 30, 15fps
• 36X Zoom*: 12X optical; 3X digital zoom
• Wide field of view: DFOV 85°; HFOV 72°; VFOV 50°
• Lens focal length: 3.9 mm (wide) → 40.37 mm (tele)
• Lens F#: 1.8 (wide) → 2.8 (tele)
• AE, white balance: auto/manual override via PTZApp 2
• Minimum focus distance: 1.5 m
• Motorized Pan & Tilt: Pan ±170°; Tilt +90° (up) −30° (down)
• Preset number: 10 via IR remote, 128 via RS232

Secondary fixed lens (AI lens)
• Image sensor: Sony EXMOR
• Frame rates & resolution set according to PTZ lens settings
• Wide field of view: DFOV 95°; HFOV 78°; VFOV 50°
*Please use PTZApp 2 to set up 36X zoom.
Innovative Features • SmartSpeaker: automatically track human voice & focus on the speaker
• Dynamic detection: secondary AI lens detects all participants
• New participants trigger PTZ lens to dynamically frame all
• Presentation tracking: voice-triggered tracking speaker with best preset
• Simultaneous 3-way output: USB, HDMI, and IP connections
• Gesture control: intuitive meeting camera controls
• Smart gallery**: individual participant visibility
• Cableless access to meetings: AVer virtual USB streaming (one RJ45 cable transfers IP streaming to USB)
• 3rd-party audio tracking support (Shure/Sennheiser/Yamaha) via AVer Preset Link**
*Make sure preset areas are within AI lens’ view.
**Download PTZApp 2 for Smart Gallery, USB virtual streaming, Preset Link.
Connectivity • USB type-B 3.1 connector (USB 2.0 compatible)
• 12V/2A DC power adapter
• Mini DIN9 for RS232 in/out (VISCA control panel + daisy chain)
• IP (RJ45)
• HDMI
• Audio line in
HDMI & PoE • HDMI 1.3: 1080p 30fps / 60fps
• PoE+: 802.3at
Video Format • YUV, YUY2, MJPEG
• Network compression: H.264, H.265
• Network protocol: RTSP, RTMP
Audio Sensor • Audio pick-up range: 10m, ±60°
• 3 pairs of sensor array (6 sensors)
• If used as audio source, may require conferencing software mic setup
USB • 3.1 Gen 1 Type-B (USB 2.0 compatible)
• UVC 1.1 (USB video), UVC 1.5*
Control • IR remote control
• VISCA/Pelco P/Pelco D via RS232 (128 presets)
• Remote side: VISCA over IP (RJ45)
• UVC plug & play
• Web UI: Chrome browser only (IE unsupported)
• OSD setting: HDMI out to TV monitor
• PTZApp 2
Power Supply • AC 100–240V, 50/60 Hz
• Consumption: 12V, 2A
• PoE+: 802.3 at
Free Applications • EZManager 2: camera management SW
• PTZApp 2: settings, Smart Gallery, USB streaming, Preset Link, AI functions, diagnostics
• EZLive: real-time streaming, annotation, image capture, video recording
Environmental Data • Operating temp: 0°C to 40°C
• Operating humidity: 20% to 80%
• Storage temp: −20°C to 60°C
• Storage humidity: 20% to 80%
Dimensions • Package dimensions: 253(L) × 253(W) × 271(H) mm
• Package weight: 4.8 kg
• Camera: 170.8(L) × 190.5(H) × 173(D) mm / 2.1 kg
• Remote control: 200 × 50 × 121 mm / 90 g
Package Contents • CAM550 unit
• Power adapter (3 m)
• USB 3.1 type-B → type-A cable (3 m)
• Mini DIN9 → DIN8 RS232 adapter cable
• HDMI cable (3 m)
• Wall mount bracket + screws
• QR code card
• Tripod screw
• Drill paper
Optional Accessories • FONE540
• Mini DIN8 → D-Sub9 RS232 cable
• Ceiling mount
• Foldable TV mount
• USB2.0 Type-B → Type-A (5 m)
• USB 3.1 Extension Cable (10/20/30 m)
• 1-Port PoE+ Injector
Security & Mount • Kensington lock
• 1/4" tripod mounting screw
• Camera wall-mount bracket included
• Optional foldable TV mount
• Optional ceiling mount
System Requirements • Windows® 7/10/11
• Mac OS X 10.7 or later
• ChromeOS v94+
Hardware Specs • 3.2 GHz Intel® Core™ i5-4460 processor
• 4 GB RAM or more
• USB 3.1 port (USB 2.0 compatible)
Warranty • Camera: 3 years*
• Accessories: 1 year
*Optional 2-year extended warranty (EU only)
Compatible Applications Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans, Intel Unite, Fuze, Adobe Connect, CyberLink U Meeting, Cisco WebEx, GoToMeeting, LiveOn, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit
