VB342 Pro

Name: VB342 Pro - PPM Audio Visual
SKU: AVER_VB342P
Price: 27830.00 ZAR
Availability: InStock

R27 830,00 incl. VAT

The VB342 Pro ’s high quality 4K PTZ lens delivers unprecedentedly vivid images and clear details. Intelligent AVer AI features come together to create a crystal-clear AI-powered meeting experience.

All-in-One 4K PTZ Technology Offers Vivid Imagery

The VB342 Pro is equipped with a comprehensive 4K PTZ camera. It delivers vivid images in any meeting. 92° FOV optical lens with 15X zoom delivers true-to-life video quality. Dual 6W speakers provide outstanding sound for small and mid-size rooms.

Auto Frame and Audio Tracking Enhance Meeting Efficiency

Audio Tracking and Auto Frame, powered by AVer’s smart AI, automatically focus and detect everyone in the room, offering optimal performance for any virtual business meeting. Sound detection technology singles out human voices and enables intelligent AI functionality.

Deliver Detail-Oriented Presentations with Presentation Tracking

When the presenter speaks in any preset area, VB342 Pro will locate and frame the area, then track and zoom in on the presenter wherever they go, even if they leave the preset location.

Smart Gallery Upgrades the Meeting Experience

Smart Gallery offers the remote site clear views of every participant using AI face and body detection to crop participants’ frames, ensuring optimal visibility for all. You can choose between headshot and half-body mode to adapt to any situation without compromise.
*Please enable this function via Room Manager (PTZApp 2).
*Smart Gallery supports up to 20 participants.

Uninterrupted Clarity Created by Audio Fence and Beamforming Technology

Silence any distraction outside of the viewing angle with AVer Audio Fence technology and turn any space into an uninterrupted meeting zone. Combined with Beamforming Technology to ensure resonant sound, the VB342 Pro creates uninterrupted virtual conferences with exceptional audio quality.

Additional information

Weight	3,1 kg
Dimensions	116 × 738 × 127 mm

Product Specifications
Camera	• 4K lens: 3X optical zoom, 15X total zoom • Viewing angles (DFOV): 92°; HFOV: 84°; VFOV: 59° • Sony 4K Ultra-sensor: crystal-clear image in any lighting • Frame Rate (16:9) 4K 30fps; 1920 × 1080, 1600 × 900, 1280 × 720, 960 × 540, 848 × 480, 800 × 448, 640 × 360 at 60, 30, 15fps; (4:3) 1280 × 960, 800 × 600, 640 × 480, 360 × 280 at 30, 15fps • Adjustable Audio Fence: blocks outside noise • True WDR up to 120dB • SmartFrame & SmartSpeaker: AI auto-framing and voice tracking • Presentation Tracking: speaker/presenter tracking • Minimum Focus Distance: 80 cm • People Counting API • Mirror, Flip, AE, White Balance: Auto/Manual
Motorized Pan & Tilt Movement	• Pan: total horizontal viewing area 180° • Tilt: total vertical viewing area 105° • Supports 10 camera presets
Audio	• 10-element beamforming microphone array • 8 meters (27 ft) pickup range • Stereo speaker with output power 12W (6W × 2 pcs) • Volume up to 96 dB SPL at 0.5m • Echo cancellation • Noise suppression
HDMI	• USB Display Adapter: built-in USB 3.1 (Gen 1) to HDMI adapter
Connectivity	• 12V/5A DC power adapter • Mini DIN 9 for RS232 connection • USB 3.1 Type-B port (USB 2.0 backward compatible) • HDMI output (via USB Display Adapter) • Phone-in (3.5 mm audio jack) / Speaker-out for A/V system • Two RJ45 ports: one for Ethernet, one for expansion speakerphone • USB 2.0 Type-A × 2: wireless connection, IFP USB touchback
Video Format	• YUV, YUY2, MJPEG • Network video compression formats: H.264, H.265 • Network protocol: RTSP, RTMP
USB	• USB 3.1 Gen 1, backward compatible with USB 2.0 • UVC 1.1 (USB Video); UAC 1.0 (USB Audio); UVC 1.5
Control	• IR remote control • VISCA / Pelco P / Pelco D via RS232 (128 presets) • VISCA over IP (RJ45) • UVC/UAC plug-and-play • WebUI via Chrome (IE not supported) • Camera Management (PTZApp 2)
Mount and Security	• Camera wall-mount bracket included • TV/Display Mount Kit (Optional) • Foldable TV Mount (Optional) • Kensington Security Lock
System Requirement	• Windows® 7/10/11 • macOS® 10.14 or later • Google ChromeOS™ 94.0.4606.114 or later
Hardware Specs	• 3.2 GHz Intel® Core™ i5-4460 processor • 4 GB RAM or more • USB 3.1 port, backward compatible with USB 2.0
Power Supply	• AC 100V – 240V, 50/60 Hz • Consumption: 12V, 5A
Software Tools	• Room Management (PTZApp 2) • Supports Windows® 7 or later, macOS® 11.6 or later • Enterprise Management (PTZ Management)
Environmental Data	• Operating temperature: 0°C ~ 40°C • Operating humidity: 20% ~ 80% • Storage temperature: −20°C ~ 60°C • Storage humidity: 20% ~ 80%
Package Contents	• VB342 Pro Camera • Power Adapter & Power Cable • Remote Control • USB 2.0 Type-B to Type-A Cable (5 m) • USB Type-A to Type-C Adapter • M5 × 8 mm Screw (×4) for Wall Mount • Wall Mount Kit • 1/4"-20 L=7.5mm Screw (×3) for Tripod
Optional Accessories	• Expansion Microphone with Cable (10 m, 20 m) • Expansion Speakerphone with Cable (10 m, 20 m) • USB 3.1 Extension Cable (10 m, 20 m, 30 m) • Wireless Dongle • TV VESA Mount Kit • USB 3.0 Type-A to Type-B Cable (3 m) • Mini DIN 6 to RS-232 Adapter • Audio-Out Converter • HDMI Cable (3 m)
Dimensions	VB370 Video Bar • Dimensions (W × H × D): 73.8 × 12.7 × 11.6 cm • Net Weight: 3.1 kg Remote Control • Dimensions (W × H × D): 14.9 × 4.2 × 1.9 cm • Net Weight: 50 g
Warranty	• Camera: 3 years • Accessories: 1 Year
Compatible Applications	Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans, Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx®, GoToMeeting®, LiveOn®, TrueConf®, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit
