VC520 Pro3

Name: VC520 Pro3 - PPM Audio Visual
SKU: AVER_VC520_Pro3_1
Price: 29450.00 ZAR
Availability: InStock

R29 450,00 incl. VAT

PRESENT WITH REALISTIC IMAGERY AND VIVID AUDIO

The VC520 Pro3 stands out as an advanced conferencing system. It boasts a 36X total zoom PTZ camera, enhanced AVer SmartFrame, Preset Framing, and a Sony WDR sensor. Additionally, the VC520 Pro3 offers 3-way outputs, including HDMI connectivity, for a wider range of streaming options and a superior video and audio experience. But what truly sets the VC520 Pro3 apart is its Smart Composition feature, an embedded AI function designed to swiftly capture high-quality closeup images of meeting participants. And with an extended speakerphone solution, the VC520 Pro3 delivers an exceptional l video conferencing experience.

Dominate the Details with 36X* Total Zoom Lens and WDR Sensor

Host flawless meetings with the VC520 Pro3’s PTZ lens that offers, boasting an impressive 80° diagonal field of view for capturing videos while offering versatile pan and tilt controls for focusing on presenters, attendees, whiteboard content, or physical objects. Harness exceptional quality of details with a 24X lossless zoom and total zoom x1. Additionally, up to 36X zoom delivers superior zoom capability for ensuring participants, content, and objects are highly vivid and detailed for in-room attendees and remote participants. Plus, the Sony WDR sensor ensures depth of diverse lighting conditions, making the VC520 Pro3 the perfect conferencing camera for mid-to-large rooms.
*Use PTZapp 2 to get up to 36X zoom

Accurate Attendee Capture with AVer Smart Composition – No Installation Required

The VC520 Pro3 is one of the first PTZ camera and audio systems on the market to offer a Smart Composition feature — typically exclusively found in enterprise-grade devices. Smart Composition uses AI algorithms to automatically frame each participant properly for meetings. Seamlessly capture individuals and bodies effortlessly and clearly. Smart Composition is hassle-free and handy. Select between multiple modes like headshot and half body views. Effortlessly switching from individual to group images, with the VC520 Pro3. Identify the most relevant participants and easy meeting setups for optimal productivity.

HDMI Empowers Dual Display and 3-Way Output for Audiovisual Versatility

The VC520 Pro3 facilitates simultaneous 1080p/60fps presentation through HDMI and USB 3.1 streaming or RTSP/RTMP H.264 broadcasting. This connectivity enables the use of a second display for lecture recording with crystal clear vividness, resulting in seamless hybrid meeting experiences for your business.

Support Video and Audio with One USB Cable Solution

Setting up the VC520 Pro3 is simple. Plugging a single USB cable into your computer allows it to be ready for action, which saves time and helps you maintain an uncluttered meeting space. Simplify your setup and reduce installation costs with the VC520 Pro3.

Exceptional Audio Quality with an Extended Speakerphone

The VC520 Pro3 delivers a consistent and well-balanced audio performance. Also, it accommodates either two extension speakerphones or one microphone pod for more versatile space coverage, thus integration gives the VC520 Pro3 the ideal choice for mid-to-large conference rooms.

Additional information

Weight	5,805 kg
Dimensions	259 × 259 × 349 mm

Product Specifications
Camera	• Sony super-low-light 8M pixel sensor, clear and natural imaging in low-light conditions, providing ultra FHD image quality • Resolution: (16:9) 1920 × 1080, 1280 × 720 at 60, 30, 15fps; 1600 × 900; 960 × 540; 848 × 480; 800 × 448; 640 × 360; (4:3) 1280 × 960, 800 × 600, 640 × 480 at 30, 15fps • SmartFrame for automatic FOV adjustment to fit all participants • Smart Composition function offers great visibility for individual participants in the meeting room • Innovative Preset Framing: Follow presenter based on preset areas • WDR: Superb backlight compensation; improving lighting in high-contrast conditions • Zoom: 36X (total zoom) (12X optical zoom) • Field of view (DFOV/HFOV/VFOV): 80.5°/72.8°/41° • Lens focal length: 3.9 mm (wide) – 46.8 mm (tele) • Lens F#: 1.6 (wide) – 2.8 (tele) • Mirror, flip, white balance: Auto/manual override via PTZApp 2 • Minimum focus distance: 1m • Standard tripod screw holes and Kensington slot • People-counting API for better understanding of meeting spaces usage *Please use PTZApp 2 to set up 36X zoom.
Speakerphone	• Echo cancellation • Advanced noise suppression • Dual omnidirectional microphone • 3.5 mm phone-in jack • 3.5 mm line-out • Speaker 6W; adjustable to 90dB SPL at 0.5m • Touch controls for volume down/up, mute, phone-in call, hang up • Bridge phone-in and USB into one call • Security: Kensington slot
Control	• IR remote control • VISCA/Pelco-D/Pelco-D via RS232 (128 preset points via VISCA command) • Remote side: VISCA over IP, IP (RJ45) • UVC/UAC plug and play • WebUI browser IP access via Chrome (Does not support Internet Explorer) • PTZApp 2
Video Format	• YUV, YUY2, MJPEG • Network video compression format: H.264 • Network protocol: RTSP, RTMP
Motorized Pan & Tilt Movement	• Pan: ±170° • Tilt: +90° (up) −30° (down) • 10 camera presets (via remote control) • Fast and quiet pan / tilt movement
Connectivity	• USB type-B 3.1 connector, backward compatible with USB 2.0 • 12V/2A DC power adapter • Mini DIN9 for RS232 in & out connection (VISCA control panel + daisy chain) • USB 3.1 Type-B connector • IP (RJ45) • HDMI out
USB	• 3.1 Gen 1 Type-B, backward compatible with USB 2.0 • UVC (USB video class) 1.1 • UAC (USB audio class) 1.0
Mount	• Camera wall-mount bracket included • Optional foldable TV mount • Optional ceiling mount
System Requirements	• Windows® 7/10/11 • Mac OS X 10.7 or later • Google Chromebook version 94.0.4606.114 or later
PC Hardware Requirement	• 3.2 GHz Intel® Core™ i5-4460 processor • 4 GB RAM or more • USB 3.1 port, backward compatible with USB 2.0
Environmental Data	• Operating temperature: 0°C ~ 40°C • Operating humidity: 20% ~ 80% • Storage temperature: −20°C ~ 60°C • Storage humidity: 20% ~ 80%
Dimensions	• Package dimensions: 259 (L) × 259 (W) × 349 (H) mm • Package weight: 4.8 kg • Camera: 150 × 153 × 182 mm / 1.53 kg • Speakerphone: 195 × 48.5 × 69.5 mm / 0.86 kg • Remote control: 200 × 50 × 21 mm / 0.09 kg
Optional Accessories	• Mini DIN8 to D-Sub9 RS232 adapter • Expansion Speakerphone • USB 3.1 USB-B to Type-A cable (3 m) • USB 3.1 Type-B to Type-A cable (5 m) • HDMI cable (3 m) • USB 3.1 Extension Cable (10/20/30 m) • 1-Port PoE+ Injector • Foldable TV mount • Ceiling mount
Web page browser requirement	• Chrome: version 76.x or above • Firefox: version 69 or above • IE: Not support
Power Supply	• AC 100V ~ 240V, 50/60 Hz • Consumption: 12V, 5A • PoE+: 802.3at
Free Applications	• EZManager 2: Camera Central Management Software • PTZApp 2: AI framing, Speaker Tracking, USB Streaming, Preset Link • EZLive: streaming / annotation / image capture / video recording
Package Contents	• VC520 Pro3 Camera • VC520 Pro3 Speakerphone • Remote control • Power adapter (10 ft / 3 m) • USB2.0 Type-B to Type-A cable (16.5 ft / 5 m) • 3.5 mm mic aux cable (3 ft / 0.9 m) • HDMI cable (3 m) • QR code card • Wall-mount bracket • 1× Tripod screw
Warranty	• Camera / Speakerphone: 3 years* • Accessories: 1 year *Optional 2-year extended warranty in EU
Compatible Applications	Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans, Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx®, GoToMeeting®, LiveOn®, Microsoft® Lync®, TrueConf®, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit
Audio Format	• AAC/LC • Network protocol: RTSP, RTMP
