AVer TR535

Name: AVer TR535 - PPM Audio Visual
SKU: AVER_TR535
Price: 120225.00 ZAR
Availability: InStock

R120 225,00 incl. VAT

Dual Lens Auto Tracking Camera

Enter the future of streaming excellence with AVer’s TR535, featuring AI auto tracking capabilities for diverse applications. The TR535 offers a stellar 30X zoom and a sweeping wide-angle view. The wide-angle lens captures the whole scene while the 4K PTZ camera zooms in for close-ups, ensuring complete coverage. Fueled by four advanced AI-driven tracking modes, the TR535 delivers unparalleled precision for broadcasting, streaming, and recording environments.

Incredible Detail X Dual Lens Design

Empower your performances with the TR535’s powerful 30X optical zoom PTZ camera delivering detailed shots of specific points of interest. Enhanced by a wide-angle camera, the TR535’s AI tracking has greater accuracy, offering expansive views for your audience. The dual lens design minimizes blind spots, ensuring nearly 360-degree coverage with remarkable tracking precision.

Dual HDMI/USB/IP. Simple Configurations Boost Your Productivity

Activate the TR535’s 4K streaming through 2 HDMI, USB, and IP ports. A pair of HDMI outputs connect to two monitors for simultaneous display and capturing. Two separate USB streams via one USB cable to PC/laptop enable independent recording and streaming. Streamline your setup for fluid video production without tangled cables.

Presenter Mode: Freedom for the Presenter

Discover dynamic tracking precision with Presenter Mode, which breaks through the boundary of the stage. This mode grants the presenter the freedom to interact with the audience while the camera smoothly tracks him/her.

Additional information

Weight	3,6 kg
Dimensions	218,5 × 202,5 × 250,7 mm

Product Specifications
PTZ Camera	General / IP Streaming / USB / Software
Image Sensor: 1/2.8" 4K Exmor CMOS Effective Picture Elements: 8 Megapixels Output Resolutions: 4K@60, 4K@59.94, 4K@50, 4K@30, 4K@29.97, 4K@27.5, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080p/24, 1080p/23.98, 720p/60, 720p/59.94, 720p/50 Minimum Illumination: 0.5 lux (IRE50, F1.6, 30fps) S/N Ratio: ≥ 50 dB Gain: Auto, Manual TV Lines: 1400 (Center/Wide) Shutter Speed: 1/1 to 1/32,000 sec Exposure Control: Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR White Balance: Auto, Manual, ATW, One Push Optical Zoom: 30X \| Digital Zoom: 12X \| Total Zoom: 360X Viewing Angles: DFOV: 69.2° (Wide) to 2.8° (Tele) HFOV: 62.3° (Wide) to 2.5° (Tele) VFOV: 37.3° (Wide) to 1.4° (Tele) Focal Length: f = 1.6 mm (Wide) to 135 mm (Tele) Aperture (Iris): F = 1.8 (Wide) to 4.7 (Tele) Minimum Working Distance: 0.1 m (Wide), 1.2 m (Tele) Pan / Tilt Angles: Pan: ±170°; Tilt: +90° / -30° Pan / Tilt Speed (Manual): Pan: 0.1°–100°/sec; Tilt: 0.1°–100°/sec Preset Speed: Pan: 200°/sec; Tilt: 200°/sec Preset Positions: 10 (IR), 256 (RS-232, RS-422, IP) Camera Control - Interfaces: RS-232 (DIN8), RS-422 (RJ45), IP Camera Control - Protocols: VISCA (RS-232/RS-422/IP), PELCO-D & PELCO-P (RS-232/RS-422), CGI (IP), ONVIF Image Processing: Noise Reduction (2D/3D), Flip, Mirror, WDR, BLC Power Frequencies: 50 Hz, 60 Hz	Power Requirement: AC 100–240V to DC 12V/2A Power Consumption: 19W PoE: PoE+ Dimensions (W × H × D): 180.0 × 192.0 × 145.0 mm Net Weight: 2.0 (±0.1) kg Application: Indoor Tally Lamp: Yes Security: Kensington Slot Remote Control: Infrared Operating Conditions: Temperature: 0 °C to +40 °C; Humidity: 20% to 80% Storage Conditions: Temperature: -20 °C to +60 °C; Humidity: 20% to 95% IP Streaming — Resolution: 4K 60fps Network Video Compress Formats: H.264, H.265, MJPEG Maximum Frame Rate: 4K 60fps Bit-Rate Control Modes: VBR, CBR (selectable) Range of Bit-Rate Setting: 512 Kbps to 120 Mbps Network Interface: 10 / 100 / 1000 Base-T *Multi-Stream Capability: 4K 60fps: RTSP, HDMI, USB & NDI® HX3 / Dante AV-H 1080p 60fps: 3G-SDI Network Protocols:** IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP/RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP
Wide-Angle / AI Camera	AV over IP / USB / Live Preview
Image Sensor: 1/2.8" 4K Exmor CMOS Effective Picture Elements: 8 Megapixels Output Resolutions: 4K/30, 1080p/60, 1080p/30 Focal Length: f = 4.5 mm (Wide) to 71 mm (Tele) Viewing Angles: DFOV: 113° (Wide) to 19° (Tele); HFOV: 96.7° to 17°; VFOV: 71° Pan / Tilt Angles: Pan: ±170°; Tilt: +90° / -30° AI Auto Tracking Functions: Presenter Mode, Zone Mode, Hybrid Mode, Segment Mode Tracking Modes: Presenter Mode, Zone Mode, Hybrid Mode, Segment Mode Privacy Protection Mechanism: Sleep Mode	AV over IP Protocols: NDI® HX3 & Dante AV-H USB Connector: USB 3.1 Gen 1 (Type-B) Video Format: MJPEG, YUY2 Maximum Video Resolution (USB): 2160p USB Video Class (UVC): UVC 1.1 USB Audio Class (UAC): UAC 1.0 Live Video Preview: Yes — PTZ Control, Image Adjustment, Exposure, White Balance, Picture Network Configuration: DHCP, IP Address, Gateway, Subnet Mask, DNS
Audio / Interface	Software Tools / Management
Channels: 2ch Stereo Codec: AAC-LC Sample Rate: 48 kHz Video Outputs: 3G-SDI, HDMI, IP, USB Audio Outputs: 3G-SDI, HDMI, IP, USB Audio Inputs: MIC In, Line In	IP Search & Configuration Tool: Supports Windows® 7 or later Enterprise Management (PTZ Management): Supports Windows® 10 or later PTZ Control Panel: Supports iOS® & iPadOS® 11 or later OBS Plugin for PTZ Cameras: Supports Windows® 8 or later, macOS® High Sierra v10.13 or later CaptureShare: Supports Windows® 7 or later, macOS® 10.14 or later Room Management (PTZApp 2): Supports Windows® 7 or later, macOS® 11.6 or later Cloud Management: Supports Windows® 7 or later, macOS® 10.9 or later
Warranty	Package Contents / Optional Accessories
Camera: 5 Years Accessories: 1 Year	Camera, Drilling Paper, Ceiling Mount Bracket (×2), Quick Start Guide, Cable Fixing Plate (×2), M2.7 × 4 mm Screw (×3), Power Adapter & Power Cord, 1/4”-20 L × 6.5 mm Screw (×2), Remote Controller, M3 × 6 mm Screw (×3), DIN8 to D-Sub9 Cable, RS-232 In/Out Y Cable, HDMI Cable (1×) Optional Accessories: AVer CC01 PTZ Camera Controller, L-Type Wall Mount
