PTZ211

R53 850,00 incl. VAT

SMART STREAMING

AVer’s PTZ211 is an advanced PTZ camera that gives you complete control over your streaming content. Enjoy professional-grade streaming with full HD 1080p outputs at 60 fps, a 12X optical zoom, and the cutting-edge SmartShoot feature. Upgrade your livestream performances and dazzle your audience with the PTZ211.

Share:

Powerful Zoom: 12X Optical Precision

Experience amazing clarity as our 12X optical zoom camera and rapid autofocus bring every participant into sharp focus. And with advanced zoom performance, you won’t overlook any crucial moment.

Elevated Clarity: FHD Resolution

The PTZ211 enhances your streaming experience with a high-quality Sony sensor and Full HD resolution. The image processor optimizes color quality automatically, whether it’s a close-up or an extreme long shot, delivering an impressive visual experience.

Simplified Connection: HDMI / USB / IP + 60fps

The PTZ211 supports seamless 60 fps streaming capabilities across HDMI, USB, and IP outputs. Free yourself from intricate settings and cable clutter, all while managing multiple devices seamlessly and maintaining smooth video streaming.

Work Like a Pro: Fast & Precise

Indulge in the versatility of customizable movement speed, ranging from 0.1° to 200° per second, ensuring exceptional agility and precision. This sensitivity and seamless multi-angle movement allow you to capture captivating footage.

SmartShoot: Your Content Matters

With its built-in SmartShoot functionality, the PTZ211 uses live Human Detection to autonomously maneuver the camera across up to 4 preset zones. The camera remains focused on the presenter, swiftly transitioning between shooting zones as needed, delivering sharp images of both the presenter and their content.

PTZ Link: Voice Tracking for PTZ Cameras

Wish you had a way to connect your PTZ camera to a microphone system? Now you can, with PTZ Link — the only software that lets you combine a PTZ camera with audio picking flexibility. Transition from your AVer Pro AV camera to an audio tracking camera with greater ease as fast! The camera automatically identifies your presenter’s voice, tracking your movement smoothly. Take advantage with PTZ Link’s seamless camera and audio integration.

Additional information

Weight 2 kg
Dimensions 14,5 × 18,0 × 19,2 mm
Product Specifications
Camera Image Sensor: 1/2.8" 1080p Exmor CMOS
Effective Picture Elements: 2 Megapixels
Output Resolutions: 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080p/24, 1080p/23.98,
  720p/60, 720p/59.94, 720p/50
Minimum Illumination: 0.4 lux (F2.0, 50 IRE)
S/N Ratio: ≥ 50 dB
Gain: Auto, Manual
Exposure Control: Auto, Manual, Priority AE (Shutter, IRS), BLC, WDR
White Balance: Auto, Manual, ATW, One Push
Optical Zoom: 12X
Digital Zoom: 12X
Total Zoom: 144X
Viewing Angle:
  • DFOV: 82.6° (Wide) to 7.7° (Tele)
  • HFOV: 72.2° (Wide) to 6.7° (Tele)
  • VFOV: 45.7° (Wide) to 3.8° (Tele)
Focal Length: f = 3.9 mm (Wide) to 46.8 mm (Tele)
Aperture (F#): F1.6 (Wide) to F2.8 (Tele)
Minimum Working Distance: 300 mm (Wide), 1.5 m (Tele)
Pan/Tilt Angles:
  Pan: ±170° / Tilt: +90° / -30°
Pan/Tilt Speed (Manual): Pan: 0.1° to 100°/sec / Tilt: 0.1° to 100°/sec
Preset Speed: Pan: 200°/sec / Tilt: 200°/sec
Preset Positions: 10 via OSD (RS232/IP), 128
Camera Control Interface: RS-232 (DIN8), RS-422 (RJ45), IP
Camera Control Protocols: VISCA (RS-232/RS-422/IP), PELCO D & PELCO P (RS-232/RS-422), CGI (IP), ONVIF
Image Processing: Noise Reduction (2D/3D), Flip, Mirror, WDR, BLC
Power Frequencies: 50 Hz, 60 Hz
AI Function: SmartShoot
Privacy Protection Mechanism: Sleep Mode
Audio Channels: 2-Channel Stereo
Codec: AAC
Sample Rate: 48 kHz
Interface Video Outputs: 3G-SDI, HDMI, IP, USB
Audio Outputs: 3G-SDI, HDMI, IP, USB
Audio Inputs: MIC-In, Line-In
Warranty Camera – 3 Years
Accessories – 1 Year
General Power Requirement: AC 100–240V to DC 12V/2A
Power Consumption: 7W (Max)
Dimensions (W × H × D): 172 × 190.2 × 145.0 mm
Application: Indoor
Security: Kensington Lock
Remote Control: Infrared
Operating Temperature: 0°C to +40°C
Storage Temperature: −20°C to +60°C
Operating Humidity: 20% to 80%
Storage Humidity: 20% to 80%
IP Streaming Resolution: 1080p/60fps
Network Video Compress Formats: H.264, H.265, MJPEG
Maximum Frame Rate: 1080p/60fps
Bit-Rate Control Modes: VBR, CBR (selectable)
Range of Bit-Rate Setting: 512 Kbps to 12 Mbps
Network Interface: 10 / 100 / 1000 Base-T
Multi-Stream Capability: Yes*
Network Protocols: TCP/ IP, UDP, ARP, IGMP, HTTP, HTTPS, DHCP, RTSP, RTP/RTCP, RTMP, SRT, NDI|HX (Optional), DNS
AV over IP Protocols NDI® HX 3 & Dante AV-H
USB Connector: USB 3.0 Type-B
Video Formats: MJPEG, YUY2
Maximum Video Resolution: 1080p/60
USB Video Class (UVC): UVC 1.1
USB Audio Class (UAC): UAC 1.0
Live Video Preview • Camera PTZ control
• White balance / image adjustment
• Network configuration
• DHCP, IP Address, Gateway, Subnet Mask, DNS
Software Tools IP Search & Configuration Tool: Supports Windows® 7 or later
Enterprise Management (PTZ Management): Supports Windows® 10 or later
PTZ Control Panel: Supports iOS® 9.0 or later
UPnP: Yes
OBS Plugin for PTZ Camera: Supports Windows® 7 or later, macOS® High Sierra v10.13 or later
CaptureShare: Supports Windows® 7 or later, macOS® 10.14 or later
Room Management (PTZApp 2): Supports Windows® 7 or later, macOS® 11.6 or later
Cloud Management: Supports Windows® 7 or later, macOS® 10.9 or later
Package Contents Camera, Drilling Paper, Ceiling Mount Bracket (2×), Quick Start Guide, Cable Fixing Plate (2×), M2.7 × 4 mm Screw (3×), Power Adapter & Power Cord, 1/4"-20 L × 6.5 mm Screw (2×), Remote Controller, M3 × 6 mm Screw (3×), DIN8 to D-Sub9 Cable, RS-232 In/Out Cable, HDMI Cable (1×)
Optional Accessories • AVer CC01 PTZ Camera Controller
• L-Type Wall Mount
