PTZ330UV2

R98 150,00 incl. VAT

Professional PTZ Camera

Amaze your audience with AVer’s PTZ330UV2 — the high-end PTZ camera that gives you full control of your streaming content. With 4K 60 fps HDMI/USB/IP outputs, a 30X optical zoom lens, and SmartShoot functionality, this advanced streaming solution is unmatched. Take your streams to the top and make a lasting impression with the PTZ330UV2!

Share:

30X Optical Performance: Harness the Power of Zoom

The 30X optical zoom camera and rapid autofocus ensure that every participant appears crystal-clear onscreen. With advanced zoom performance capturing every detail, you’ll never miss a moment of any occasion.

4K Ultra HD: A New Level of Clarity

With its industry-leading Sony sensor and 4K Ultra HD super-high resolution, the PTZ330UV2 takes every streaming experience from ordinary to stunning. And an advanced image processor automatically optimizes the quality of every shot, whether it’s a close-up or an extreme long shot.

HDMI/USB/IP + 4K 60 fps: Smoother Streams

NDI® has praised the PTZ330UV2 for its real 4K 60 fps streaming capabilities via HDMI, USB, and IP outputs. With no complicated settings or tangled cords to manage, you can easily use multiple devices at the same time and still get a smoother video streaming experience.

0.1° to 200° Per Second Precision: Pro Camera Control

Customizable movement speed settings, ranging from 0.1° to 200° per second, offer high-level agility and precision for ultimate motion control during streams. The resulting sensitive and smooth multi-angle movement lets you capture extraordinary footage that dazzles your audience.

SmartShoot: Keep People and Content in Focus

With embedded SmartShoot, the PTZ330UV2 uses real-time Human Detection to automatically move the camera smoothly between up to 4 preset zones. The camera focuses on the presenter to quickly switch between shooting zones whenever they do, delivering consistently clear images of them and their content.

PTZ Link: Bring Voice Tracking to PTZ Cameras

PTZ Link is the only software that lets you connect PTZ Cameras to microphone systems. With the help of PTZ Link, you can easily turn your AVer PTZ Camera into a voice tracking camera by setting preset areas that let the camera automatically switch focus between different speakers in those spaces. Leverage seamless camera and audio integration with PTZ Link to experience ultimate-quality streams.

Additional information

Weight 2 kg
Dimensions 145 × 180 × 192 mm
Product Specifications
Camera Image Sensor: 1/2.8" 4K Exmor CMOS
Effective Picture Elements: 8 Megapixels
Output Resolutions:
4K/60, 4K/59.94, 4K/50, 4K/30, 4K/29.97, 4K/25,
1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080p/24, 1080p/23.98,
720p/60, 720p/59.94, 720p/50
Minimum Illumination: 0.5 lux (IRE50, F1.6, 30fps)
S/N Ratio: ≥ 50 dB
Gain: Auto, Manual
TV Lines: 1400 (Center/Wide)
Shutter Speed: 1/1 to 1/32,000 sec
Exposure Control: Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance: Auto, Manual, ATW, One Push
Optical Zoom: 30X
Digital Zoom: 12X
Total Zoom: 360X
Viewing Angles:
DFOV: 69.2° (Wide) to 2.8° (Tele) • HFOV: 62.3° (Wide) to 2.5° (Tele) • VFOV: 37.3° (Wide) to 1.4° (Tele)
Focal Length: f = 1.6 mm (Wide) to 135 mm (Tele)
Aperture (Iris): F = 1.8 (Wide) to 4.7 (Tele)
Minimum Working Distance: 0.1 m (Wide), 1.2 m (Tele)
Pan / Tilt Angles: Pan: ±170°; Tilt: +90° / -30°
Pan / Tilt Speed (Manual): Pan: 0.1° to 100° / sec; Tilt: 0.1° to 100° / sec
Preset Speed: Pan: 200° / sec; Tilt: 200° / sec
Preset Positions: 10 (IR), 256 (RS-232, RS-422, IP)
Camera Control - Interfaces: RS-232 (DIN8), RS-422 (RJ45), IP
Camera Control - Protocols: VISCA (RS-232 / RS-422 / IP), PELCO-D & PELCO-P (RS-232 / RS-422), CGI (IP), ONVIF
Image Processing: Noise Reduction (2D / 3D), Flip, Mirror, WDR, BLC
Power Frequencies: 50 Hz, 60 Hz
AI Function / Mode: SmartShoot
Privacy Protection Mechanism: Sleep Mode
Audio Channels: 2ch Stereo
Codec: AAC-LC
Sample Rate: 48 kHz
Interface Video Outputs: 3G-SDI, HDMI, IP, USB
Audio Outputs: 3G-SDI, HDMI, IP, USB
Audio Inputs: MIC In, Line In
Warranty Camera: 5 Years    Accessories: 1 Year
Package Contents Camera, Drilling Paper, Ceiling Mount Bracket (×2), Quick Start Guide, Cable Fixing Plate (×2), M2.7 × 4 mm Screw (×3), Power Adapter & Power Cord, 1/4"-20 L × 6.5 mm Screw (×2), Remote Controller, M3 × 6 mm Screw (×3), DIN8 to D-Sub9 Cable, RS-232 In/Out Y Cable, HDMI Cable (1×), Optional L-Type Wall Mount
General Power Requirement: AC 100 - 240V to DC 12V/2A
Power Consumption: 19W
PoE: PoE+
Dimensions (W × H × D): 180.0 × 192.0 × 145.0 mm
Net Weight: 2.0 (±0.1) kg
Application: Indoor
Tally Lamp: Yes
Security: Kensington Slot
Remote Control: Infrared
Operating Conditions: Temperature: 0 °C to +40 °C ; Humidity: 20% to 80%
Storage Conditions: Temperature: -20 °C to +60 °C ; Humidity: 20% to 95%
IP Streaming Resolution: 4K 60fps
Network Video Compress Formats: H.264, H.265, MJPEG
Maximum Frame Rate: 4K 60fps
Bit-Rate Control Modes: VBR, CBR (selectable)
Range of Bit-Rate Setting: 512 Kbps to 120 Mbps
Network Interface: 10 / 100 / 1000 Base-T
Multi-Stream Capability*:
4K 60fps: RTSP, HDMI, USB, & NDI® HX3 / Dante AV-H
1080p 60fps: 3G-SDI
Network Protocols:
IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP
AV over IP Protocols NDI® HX 3 & Dante AV-H
USB Connector: USB 3.1
Video Formats: MJPEG, YUY2
Maximum Video Resolution: 2160p
USB Video Class (UVC): UVC 1.1
USB Audio Class (UAC): UAC 1.0
Live Video Preview Yes — Camera PTZ Control, Camera / Image Adjustment, Exposure, White Balance, Picture, Network Configuration (DHCP, IP Address, Gateway, Subnet Mask, DNS)
Software Tools IP Search and Configuration Tool: Support Windows® 7 or later
Enterprise Management (PTZ Management): Support Windows® 10 or later
PTZ Control Panel: Supports iOS & iPadOS® 11 or later
OBS Plugin for PTZ Cameras: Supports Windows® 8 or later, macOS® High Sierra v10.13 or later
CaptureShare: Supports Windows® 7 or later, macOS® 10.14 or later
Room Management (PTZApp 2): Supports Windows® 7 or later, macOS® 11.6 or later
Cloud Management: Supports Windows® 7 or later, macOS® 10.9 or later
